Body

• Durable aluminum body with 360° rotation and 80° tilting.

LED Characteristics

• This general application light fixture features a 9 watt LED module that maintains uniform intensity producing up to 875 lumens; with a typical CRI of 90. With a CCT range of 2700 K – 5000 K color temperature.

Dimming

• 100%-10% dimming capability. This fixture is compatible with industry standard TRIAC/ELV dimmers.
• For compatible dimmers, visit www. liteline.com/Orbit

Beam Spread

• The fixture lens provides 36° beam spread.

Mounting

• Includes two spring loaded clips to attach to any ceiling material.

LED Driver

• Extruded aluminum hardwire box with 210mA dimmable class II electronic LED driver with 100-135V, 60Hz AC input.
• Includes an 15″ FT6 rated cable with 3-pin DC connector between driver and fixture approved for use in plenums and suspended ceilings.
• Includes 5 position CCT switch.

Quick Connect push-in terminals

• Three “Quick connect” push-in terminals for fast and easy wiring.

Operating Temperature

• -40°C~40°C (-40°F~104°F)

Environment

• Suitable for wet locations.
• Approved for direct contact with insulation.
• Airtight
• Indoor / Outdoor rated.
