optical

• Luminous flux according to Bining : 800 lumens.
• Colour temperature : 2700 K to 4000 K (2 at 3 Macadam step).
• Service Range : 70 % of nominal flux after 50 000 hours.
• Colour Rendering Index : CRI 90.
• PMMA acrylic lens, efficiency ~90 %. Interchangeable lens.
• Available degrees : 15°, 25°, 40° et ELL.

electrical

• Constant current supply :  0,7A.
• Supply connection : Polarised output connectors.
• Power consumption to  8W max, excluding supply.
• Electrical Classification : Class III SELV device.

mechanical

• Dimensions : Diameter 70 mm, Overall Height  49mm.
• Adjustable to a total angle of 50°.
• Operating temperature : -5° +40°.
• ROHS components.
• Interior use only.
